The Shaanxi Baojii Specialty Vehicles Lie Ying (猎鹰, lit. "Falcon"), otherwise known as Falcon Strike Gyrocopter, is a Chinese autogyro that was designed and produced by the Shaanxi Baojii Special Vehicles Manufacturing Company of Baoji in Shaanxi province. The aircraft was supplied complete and ready-to-fly.
The manufacturer is a well-known builder of armoured vehicles for police and military use and the aircraft was reportedly flying in 2015, but the original website was taken down in late 2016. However, there is a new company website.
The aircraft gained media attention when it appears as part of 2019 China National Day military parade. Nicknamed "air tricycle". In 2022 the aircraft reportedly costs approximately 40,000 Chinese Yuan (approximately 5,500 USD).
Design and development
The Falcon was designed for police and military use as a surveillance aircraft. It features a single main rotor, a two-seats-in tandem open cockpit with a windshield, tricycle landing gear and a Rotax 914 engine in pusher configuration. The Rotax engine is an Austrian-made, four-cylinder, liquid- and air-cooled, four stroke turbocharged 115 hp (86 kW) unit.
The aircraft has a two-bladed rotor with a diameter of 8.4 m (27.6 ft). It has a typical empty weight of 290 kg (639 lb) and a gross weight of 560 kg (1,235 lb), giving a useful load of 270 kg (595 lb). With full fuel of 70 litres (15 imp gal; 18 US gal) the payload for the crew and mission equipment is 220 kg (485 lb).
The basic model of the aircraft is a two-seater. An upgraded three-seater version of the aircraft also exists. The three-seat variant feature a 135 hp (101 kW) engine, a larger fuel tank made from different materials, to give greater range, and allow the transportation of more cargo, as well as for parachuting operations.
The aircraft can be armed with anti-tank guided missiles. The two-seater version can carry four missiles on hardpoints.
Specifications (Falcon)
Data from Tacke
General characteristics
- Crew: one
- Capacity: one passenger
- Empty weight: 290 kg (639 lb)
- Gross weight: 560 kg (1,235 lb)
- Fuel capacity: 70 litres (15 imp gal; 18 US gal)
- Powerplant: 1 × Rotax 914 four cylinder, liquid and air-cooled, four stroke turbocharged aircraft engine, 75 kW (100 hp)
- Main rotor diameter: 8.4 m (27 ft 7 in)
- Main rotor area: 55 m2 (590 sq ft)
- Propellers: 3-bladed composite
Performance
- Maximum speed: 180 km/h (110 mph, 97 kn)
- Cruise speed: 150 km/h (93 mph, 81 kn)
- Rate of climb: 2.5 m/s (490 ft/min)
- Disk loading: 10.2 kg/m2 (2.1 lb/sq ft)
